M18 FUEL™ 16 Gauge Angled Finish Nailer

Our M18 FUEL™ 16 Gauge Angled Finish Nailer provides peak productivity at your jobsite, delivering unmatched nailing performance without the hassle of a compressor and hose. Leveraging our nitrogen air spring mechanism, the 16 Gauge Angled Finish Nailer allows you to consistently sink nails to your required depth in hard and soft woods while leaving clean nail holes, making for repeatable results and easy filling. The nitrogen air spring mechanism, combined with our POWERSTATE™ Brushless Motor and REDLINK PLUS™ Intelligence, delivers a pneumatic-like nailing response with zero ramp-up time from nail to nail, keeping you productive and efficient throughout your job. This cordless finish nailer features a compact and ergonomic design providing access into tight spaces where nailing is required while limiting fatigue when using the tool. When paired with an M18™ REDLITHIUM™ CP2.0 battery pack, this battery-powered nailer fires up to 800 nails per charge and is fully compatible with all M18™ REDLITHIUM batteries. The MILWAUKEE® M18 FUEL™ 16 Gauge Angled Finish Nailer delivers the pneumatic performance that professional carpenters and remodelers demand, with the freedom and convenience of cordless.

16 Gauge Angled Finish Nailer

Consistent
Clean
Nail Holes
Compact
Size
Zero
Ramp-Up
Time

CONSISTENT, CLEAN NAIL HOLES

  • Consistently drives nails subflush in both hardwoods and softwoods

COMPACT SIZE

  • Clear line of sight for accurate nail placement
  • Reduced size for increased access in corners and tight spaces

ZERO RAMP-UP TIME

  • No delay between trigger pull and nail fire
  • Fires 3 nails per second
M18

PERFORMANCE DRIVEN
TRADE FOCUSED
SYSTEM WIDE

  • Tool Free Depth Adjustment
  • Tool Free Jam Clearing Latch
  • Sequential and contact actuation firing modes
  • Tip Storage On Magazine
  • LED Work Light
  • Reversible Belt Hook
  • No Gas Cartridge
  • Power to Nail Hardwoods & Softwoods
  • Compatible with all 16GA Angled Finsih Nails
  • Part of the M18™ system, featuring over 200+ solutions
  • POWERSTATE™ Brushless Motor delivers longer life and higher performance
  • REDLINK PLUS™ Intelligence: Provides optimized performance and overload protection using total system communication between tool, battery and charger
  • Fires 3 Nails Per Second
  • Fires 800 Nails Per Charge on M18™ CP2.0 Battery
  • 110 Nail Magazine Capacity
You May Also Like...

Product Specifications

Nailer Type Finishing
Tool Warranty 5 Year Limited Warranty
Power Source Cordless
Length 12.75 in
Weight 6.5 lb
Height 12 in
Width 5.9 in
Nail Diameter 16GA Angled
Nail Collation Angle 20 Degrees
Nail Length 1 1/4" - 2 1/2"
Voltage 18V
Battery System M18
